Lift-off hinges GN 161.1 are a unique variation with a highly attractive design. The mounting screws are concealed.
During load tests, these hinges were gradually loaded and relieved at room temperature with incrementally increasing force.
For the specified values, an insignificant permanent deformation remained after relieving the load which had no effect on the function and appearance. In most cases, the failure loads are multiples of the specified value.
Indicated load bearing capacities are non-binding recommended values and constitute no general warranty of quality and condition. The user must determine from case to case whether a product is suitable for the intended use. Environmental influences and aging may influence these values.
Hinge leafs
Zinc die-cast, powder coated
Washer
Plastic
RoHS
| b | l1 | d | l2 | l3 | l4 | l5 | m | t1 | t2 | Radial load | Axial load |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.59 | 2.48 | 10 x 32 | 0.67 | 1.22 | 0.24 | 0.39 | 0.75 | 0.20 | 0.39 | 517 lbf (2300 N) | 337 lbf (1500 N) |
| b | l1 | d | l2 | l3 | l4 | l5 | m | t1 | t2 | Radial load | Axial load |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.59 | 2.48 | M 5 | 0.67 | 1.22 | 0.24 | 0.39 | 0.75 | 0.20 | 0.39 | 517 lbf (2300 N) | 337 lbf (1500 N) |
| Min | Max | Price |
|---|---|---|
| 1 | 49 | $11.60 |
| 50 | 99 | $10.64 |
| 100 | 249 | $9.67 |
| ≥ 250 | $8.70 |
